Emelcold 3 Ton Split Air Conditioner Model: EMS-2T36KC(2)

Power Supply : 1Ph-V-Hz: 1Ph-220-240V-50Hv
Type: Cooling Only
Control Type: Remote Controller
Cooling (Tested) Capacity(T1/T3): 32000/26560 BTU/h
Cooling (Tested) Power Input(T1/T3): 3220/3730 W
Cooling (Tested) Rated Current(T1/T3): 14.7/16.5 A
Cooling (Tested) EER(T1/T3): 10.52/7.6 (BTU/h)
Compressor Type: PISTON
Compressor Brand: KK THAILAND
Compressor Indoor air flow: 1350 m3/h
Indoor Unit Noise level: 47 dB(A)
Indoor Unit Unit dimension (W*H*D): 1460mm * 348mm * 280mm
Packing(W*H*D): 1575mm * 455mm * 355mm
Outdoor Unit Noise Level: 62 dB(A)
Outdoor Unit Unit Dimension(W*H*D): 1235mm * 400mm * 940mm
Outdoor Unit Packing(W*H*D): 1330mm * 453mm * 1056mm
Refrigerant type: R22
Refrigerant Pipe Liquid Side mm: 9.52mm
Refrigerant Pipe Gas side mm: 15.88mm
Refrigerant Pipe Max. refrigerant pipe length: 15m
Refrigerant Pipe Max. difference is level: 8m
Loading Quality 40HQ: 75
